5" Heavy Swivel Caster Polyurethane on Metal Core with Ball Bearings - 1,000 lbs Cap.

🛞 5" x 2" Medium Heavy-Duty Caster – 1,000 lb Capacity

Engineered for strength and smooth mobility, this Series #30 caster is built to handle demanding environments with ease.  Non-locking.

Specifications:

• Wheel Size: 5" x 2"

• Load Capacity: 1,000 lbs

• Top Plate: 4" x 4-1/2"

• Bolt Hole Pattern: 2-5/8" x 3-5/8" to 3" x 3"

• Bolt Size: 3/8" (hardware not included)

• Mounting Height: 6-1/2"

• Wheel Bearings: Pedestal Precision Ball Bearings (manual speeds up to 3 mph)

• Tread Hardness: 90–95 Shore A Durometer

Features:

• Green polyurethane tread on black semi-steel core

• Bright zinc-plated finish for corrosion resistance

• 1/2" diameter axle bolt with grease fittings

• Double ball bearing heat-treated raceways

• 5/8" bolted kingpin for added durability

Applications: Ideal for dollies, platform trucks, drywall carts, welding carts, wall panel carts, warehouse equipment, food service carts, and hotel housekeeping carts.
